ORDER INFORMATION
EAN Number 5702663016064
CHARACTERISTICS
Max. output level SAT @ -35 dB IMD3 100 dBµV
LNB power supply max. 1.3 V/DC
Switch commands 13/18 V, 0/22 kHz, DiSEqC 2.0, Toneburst
FREQUENCY
Frequency range TER 5-862 (passiv) MHz
Frequency range SAT 950-2150 (aktiv) MHz
GAIN
Gain – SAT (with 5 dB slope) – 2.0 dB
Gain – TER – 21.0 dB
ISOLATION
Isolation LNB to LNB 35.0 dB
Isolation SAT to TER 30.0 dB
Isolation TER to SAT 20.0 dB
Isolation cross polarisation H/V 28.0 dB
Isolation out-out SAT 30.0 dB
Isolation out-out TER 25.0 dB
RETURN LOSS
Return loss SAT inputs 12.0 dB
Return loss SAT outputs 12.0 dB
Return loss TER inputs 8.0 dB
Return loss TER outputs 8.0 dB
ELECTRICAL
Impedance 75 Ω
Power link (for amplifiers in the line) Yes
OPERATIONAL
DC Operating voltage 15.0 ± 0.5 VDC
Control LEDs Green for power, Yellow for power link
Temperature – operating 0 – 55 °C
CONNECTORS
Connector Type F-female
Number of inputs 17
Number of trunk inputs 16 SAT, 1 TER
Subscriber outputs 6
Colorcoding @IF/TER inputs VL=Black, VH=Red, HL=Green, HH=Yellow, Clear=TER
MECHANICAL
Main material Steel housing
Product Height 55 mm
Product Depth 125 mm
Product Width 355 mm
Packing QTY 1
Packaging Height 0,080 m
Packaging Width 0,140 m
Packaging Depth 0,400 m
Packaging Volume 0,004 m3
Net Weight 1,000 kg
Tara Weight 0,050 kg
Total Weight 1,050 kg
