Satelitske antene Zemaljske antene Bazne stanice Multiswitch Kabeli POJAČALA Aktualno Pojačalo/ pretvarač kanala Triax TMB 2500Procesor zemaljskih kanala TRIAX TMB 2500Vrhunska programabilna višepojasna pojačala Oslobodite najbolje iskustvo uz TMB 2500.Programabilni zemaljski kanalni procesor može primati TV signale s više zemaljskih antena. Kombinira filtriranje, pretvaranje, izjednačavanje razine i pojačanje kanala emitiranja – sve to unutar vrlo kompaktne jedinice kako bi se pojačao zbrojni signal u koaksijalnu TV distribucijsku mrežu u velikim višestambenim ili ugostiteljskim objektima. 5 antenskih ulaza: FM / 4xVHF/UHF ORDER INFORMATION EAN Number5702663602328 ELECTRICAL Impedance 75 Ω CONNECTORS Number of inputs1xFM 4xVHF(DAB)/UHF Number of outputs1x FM/DAB/VHF/UHF + 1x Test port FREQUENCY RANGE Frequency Range FM 88…108 MHz Frequency Range DAB 174…240 MHz Frequency range VHF 174…240 MHz Frequency range UHF 470…862 MHz Number of channels> 50 by 32 filters LTE protectionAuto: 694/790/OFF GAIN Gain FM 35 dB Gain – VHF 75 dB Gain – UHF 75 dB Slope 15 dB CHARACTERISTICS MER 35 dB Input Level – FM 37…77 dBµV Input Level – VHF 45…109 dBµV Input Level – UHF 45…109 dBµV Output level FM 113 dBµV Output level @ 60dB IMR3 – UHF 120 dBµV Output level @ 60dB IMR3 – VHF 120 dBµV Output Level VHF/UHF 1MUX 118 dBµV Output Level VHF/UHF 6MUX 114 dBµV Selectivity 50 dB/1MHz Test Point – 30 dB LOSS Attenuator FM 0…20 dB Attenuator Sum Output 0…20 dB OPERATIONAL AC Supply voltage 100…240 VAC Power Consumption (typ.) 15 W PSU/adapter INFOIncluded Euro Plug (CEE 7/17) Remote Voltage Preamp 12/24 VDC Temperature – operating -5…50 °C MECHANICAL Dimensions product (H x D x W) 165 x58 x165 mm Packing QTY1 Product Height 53 mm Product Width 170 mm Product Depth 167 mm Packaging Height 0.075 m Packaging Width 0.227 m Packaging Depth 0.270 m Packaging Volume 0.004 m3 Net Weight 0.872 kg Tara Weight 0.216 kg Total Weight 1.088 kg... Pojačalo/ pretvarač kanala Triax TMB 1500Procesor zemaljskih kanala TRIAX TMB 1500Revolucija u programabilnim višepojasnim pojačalima Programirani procesor zemaljskih kanala TMB 1500 može primati TV signale s više zemaljskih antena. Kombinira filtriranje, pretvaranje, izjednačavanje nivoa i pojačavanje emitiranih kanala – sve to u vrlo kompaktnoj jedinici kako bi se zbroj signala pojačao u koaksijalnoj TV distribucijskoj mreži u više stanova ili ugostiteljskim objektima. 4 antenska ulaza: FM / DAB-VHF / 2xUHF Fleksibilna matrica s 15 filtara po 1 … 6 MUX-u za pojedinačnu obradu kanala na bilo koji izlazni kanal AGC u stvarnom vremenu odvojeno na svim multipleksima Potiskivanje susjednih kanala od 50 dB Automatsko prebacivanje između odbijanja LTE 700-5G i 800-4G Mogućnost kompenzacije nagiba kabela smanjenjem FM i DAB-VHF izlazne razine u usporedbi s UHF razinom Postavljanje zaključavanja sigurnosnim kodomPreklopno daljinsko napajanje za predpojačala 0/12/24 VDC Desktop PSU s Euro mrežnim utikačem ORDER INFORMATION EAN Number 5702663602311 CHARACTERISTICS MER 35 dB Input Level – FM 37…77 dBµV Input Level – VHF 45…109 dBµV Input Level – UHF 45…109 dBµV Output level FM 113 dBµV Output level @ 60dB IMR3 – UHF 115 dBµV Output level @ 60dB IMR3 – VHF 115 dBµV Output Level VHF/UHF 15MUX 108105 dBµV Selectivity 50 dB/1MHz Test Point – 30 dB FREQUENCY Frequency Range FM 88…108 MHz Frequency Range DAB 174…240 MHz Frequency range VHF 174…240 MHz Frequency range UHF 470…862 MHz Number of channels > 50 by 15 filters LTE protection Auto: 694/790/OFF GAIN Gain FM 35 dB Gain – VHF 60 dB Gain – UHF 60 dB Slope 9 dB LOSS Attenuator FM 0…20 dB Attenuator Sum Output 0…20 dB ELECTRICAL Impedance 75 Ω OPERATIONAL AC Supply voltage 100…240 VAC Power Consumption (typ.) 12 W PSU/adapter INFO Included Euro Plug (CEE 7/17) Remote Voltage Preamp 12/24 VDC Temperature – operating -5…50 °C CONNECTORS Number of inputs 1xFM 1xDAB/VHF 2xUHF Number of outputs 1x FM/DAB/VHF/UHF + 1x Test port MECHANICAL Dimensions product (H x D x W) 165 x58 x165 mm Packing QTY 1 Packaging Height 0,068 m Packaging Width 0,270 m Packaging Depth 0,228 m Packaging Volume 0,004 m3 Net Weight 1,050 kg Tara Weight 0,220 kg Total Weight 1,270 kg...
